How to Choose the Right High Voltage Switchgear: 5 Key Considerations

High voltage switchgear is essential for safe and reliable power distribution in electrical systems. Whether you're managing an industrial facility, renewable energy plant, or utility substation, choosing the right switchgear can significantly impact system performance and safety.

In this blog post, we’ll walk you through five key considerations that will help you choose the most suitable high voltage switchgear for your project.

1. Voltage Rating – Know Your System Requirements

One of the first and most important steps is selecting the correct voltage level for your switchgear.

Common voltage ratings include 11kV, 33kV, 66kV, 110kV, and higher.

The voltage rating should match or slightly exceed the system’s operating voltage.

Also consider the Basic Insulation Level (BIL) to ensure proper protection during voltage surges.

Never underestimate the importance of insulation coordination in high-voltage environments.

2. Rated Current – Match Your Load Capacity

The rated current defines how much current the switchgear can handle continuously without overheating.

Typical current ratings range from 630A to 4000A, depending on application.

Make sure it supports your normal operating load and future expansion.

3. Short-Circuit Breaking Capacity – Protect Against Faults

High voltage systems must be ready to handle fault conditions. The short-circuit breaking capacity indicates how much fault current the switchgear can interrupt safely.

Expressed in kA (e.g., 25kA, 31.5kA, 40kA) for a defined duration (usually 1 or 3 seconds).

A low breaking capacity in a high-fault-current network can be catastrophic.

Always verify the fault level of your network before finalizing the switchgear specs.

4. Installation Environment – Choose the Right Type

Where and how you install your switchgear matters just as much as the ratings.

Indoor vs Outdoor: Indoor applications may use air-insulated (AIS) or gas-insulated (GIS) types. Outdoor switchgear needs to be weatherproof and corrosion-resistant.

Environmental factors: Consider humidity, altitude, pollution levels, and seismic activity.

In harsh conditions, choose ruggedized switchgear with suitable protection (e.g., IP65, stainless steel enclosures).

5. Think Long-Term

Price is important, but the total cost over the switchgear’s life cycle is even more critical.

Consider:

Initial purchase and installation costs

Maintenance and inspection frequency

Downtime risks

Spare parts availability

Energy losses and efficiency

For compact spaces or maintenance-free operations, GIS may offer better long-term value than AIS despite higher upfront cost.

Selecting the right high voltage switchgear isn’t just about meeting technical specs—it’s about ensuring long-term reliability, efficiency, and safety for your electrical system.

System voltage level

Rated current capacity

Short-circuit protection

Environmental conditions

Total cost of ownership
